MARANTZ MODEL M4 / 8 Channel 100W Distribution Amplifier Powered by HEOS™
SKU : Marantz M4
ขายแล้ว 0 ชิ้น
฿149,000
จำนวน
คำอธิบายสินค้าแบบย่อ
8 Channel 100W Distribution Amplifier Powered by HEOS™
รายละเอียดสินค้า
8 × 100W per channel Four-Zone Distribution Amplifier with HEOS® Built-in
Four-Zone Distribution Amplifier
MODEL M4
• 8 × 100W Amplification (8 ohm 20-20kHz) 0.05% THD
• 192/24 FLAC, ALAC, WAV, DSD
• Stereo RCA in ×4, Optical ×2, Ethernet ×2, USB-A ×4
• HEOS®
, AirPlay 2, Dolby Digital
• Stereo preouts per zone or four subwoofer outputs, one per zone
• Convert preout to subwoofer out with High Pass and Low Pass Filters
• TV Sound Grouping
• Marantz Musical Digital Filtering (MMDF)
• 12V trigger out per zone and Bridge mode
• Perfectly sized for ra
Amplifier
Audio Inputs / Outputs
Audio Options
Audio Format Support
Streaming Technologies
Music Services and Sources
Networking & Control
General
Four-Zone Distribution Amplifier
MODEL M4
• 8 × 100W Amplification (8 ohm 20-20kHz) 0.05% THD
• 192/24 FLAC, ALAC, WAV, DSD
• Stereo RCA in ×4, Optical ×2, Ethernet ×2, USB-A ×4
• HEOS®
, AirPlay 2, Dolby Digital
• Stereo preouts per zone or four subwoofer outputs, one per zone
• Convert preout to subwoofer out with High Pass and Low Pass Filters
• TV Sound Grouping
• Marantz Musical Digital Filtering (MMDF)
• 12V trigger out per zone and Bridge mode
• Perfectly sized for ra
Amplifier
- Power Amplifier Rated output & THD (8 ohm) 8 × 100 W (8 Ω/ohms, 20 Hz to 20 kHz, T.H.D. 0.05 %)
- Power Amplifier Rated output & THD (4ohm) 8 × 125 W (4Ω/ohms, 1 kHz, T.H.D. 0.1%)
- Frequency Response 20 Hz to 20 kHz : ±1 dB
- Connected loudspeaker Impedance 4 – 16 Ω/ohms
Audio Inputs / Outputs
- Loudspeaker Binding Posts 4-way binding posts
- Digital Inputs TOSLINK (2)
- Analog Inputs RCA L/R (4)
- Preouts RCA L/R (4)
- Subwoofer Out RCA Mono (4) (selectable)
Audio Options
- Channel Assignments Stereo (Default), Dual Mono
- Volume Limit 80-100%
- Balance -15dB to +15dB
- Adjustable High Pass / Low Pass Filters 40-250 Hz / 40-120 Hz
- EQ Bass, Treble -5dB to +5dB
- Sound Modes Stereo, Direct, Virtual,
- Dialog Enhancer, Night Mode
- TV Sound Grouping Yes
Audio Format Support
- Decoding Dolby Digital, LPCM, DSD
- Stereo PCM / Multi-channel PCM Yes / Yes
- Stereo File Formats (HEOS® network share or USB)
- WMA: up to and including 192 kbps
- AAC & MP3: up to and including 320 kbps
- WAV, ALAC, FLAC: up to and
- including 24-bit/192kHz
- DSD: 2.8 MHz, 5.6MHz
Streaming Technologies
- Bluetooth Receive N/A
- Bluetooth Transmit N/A
- AirPlay AirPlay 2
- Spotify Spotify Connect
Music Services and Sources
- Music Services Supported (HEOS®, subject to change and local availability)
- Pandora, Spotify, TuneIn, SiriusXM, Amazon Music, Tidal, Tidal HiRes, iHeartRadio, Deezer,
- Deezer HiFi, Mood:Mix, Sony Hi-Res, AWA, QPlay, SoundCloud
- Music stored on mobile device Yes (iOS, Android or Kindle Fire)
- NAS (Network Attached Storage) Network share
- USB Storage Device Playback Yes (4) (FAT32, NTFS formatted drives)
Networking & Control
- Wired Connectivity Ethernet (2)
- Wireless Connectivity N/A
- IR Input N/A
- IR Learning N/A
- Control System Compatibility via TCP/IP Crestron, Control4, AMX
- HEOS® App iOS, Android, Kindle Fire
- Trigger Output DC 12V Yes (4)
General
- Product Color Black
- User Interface Reset button, Front power button,
- Rear power switch
- Dimensions (W × D × H) Inches 17.4 × 16.34 × 4.17
- Dimensions (W × D × H) mm 442 × 415 × 106
- Weight (lbs) 18
- Weight (kg) 8
