Audiolab 6000A Integrated Amplifier with Bluetooth

6000A
An amplifier remains the beating heart of any high-performance audio system, a truly versatile integrated amp needs to cover many bases digital and analogue sources, wireless connectivity for portable devices, a phono stage to cater for vinyl playback, amplification for headphones as well as speakers Thats a lot to pack in, whilst keeping performance high and the price tag affordable and yet, thats exactly what the 6000A

Gain (max.) :
+8dB (Line)
+55dB (Phono MM)

Input Sensitivity :
720mV (Line, Volume = 0dB)
3.1mV (Phono MM, Volume=0dB)

Input Impedance :
10K (Line)
47K//100pF (Phono MM)

Total Harmonic Distortion (THD): < 0.0004% (Line, 1KHz @ 2V, Volume = 0dB)
Frequency Response: 20Hz-20kHz (+/-0.1dB)
Output Voltage: 2.3V max. (Volume = 0dB)
Output Impedance: 120

DAC:
D to A converter
ES9018K2M

Total Harmonic Distortion (THD) : < 0.0006% (1kHz @ 0dBFS)
Output level (0dBFS, 1KHz): 2.05V
Max. Sampling Frequency: 192kHz
Signal-to-noise ratio (S/N): > 112dB (A-weighted)
Digital Filters: Fast Roll-off , Slow Roll-off , Minimum Phase

Power Amplifier Section :
Gain
+29dB

Rated Max. Power Output :

• 2 X 50W (8, THD<1%)
• 2 X 75W (4, THD<1%)

Frequency Response: 20Hz-20kHz (+/-0.3dB)

Input Sensitivity: 720mV

Total Harmonic Distortion (THD): <0.003% (1kHz @ 40W/8)

Signal-to-Noise ratio (S/N): > 110dB (A-weighted)

Max. Output Current: 9A

Headphone Amplifier :

• Total Harmonic Distortion (THD): < 0.01% (1kHz, 50mW)
• Output Impedance: 2.35
• Load impedance : 20-600
