Quad Revela 1 Bookshelf Speakers

Specifications :

*General Description Bookshelf

*Enclosure Type Bass reflex

*Transducer Complement 2-way

*Bass Driver 165mm advanced fibre cone

Midrange Driver :

*Treble Driver 27 x 60mm true ribbon

*AV Shield No

*Sensitivity (2.83V @lm) 86dB

*Recommended Amplifier power 30-120w

*Peak Power Handling 120w

*PeakSPL 102dB

*Nominal Impedance 6Ω

*Minimum Impedance 4.1Ω

*Frequency Response ( + / -3dB) 54Hz 24kHz

*Bass Extension (-6dB) 40Hz

*Crossover Frequency 2.9kHz

*Cabinet Volume (in litres) 17.6L

Dimensions :

*Height (on plinth & spikes) 395mm

*Width 246mm

*Depth(inc Grille and Terminals) 312mm

*Carton Size 650mm x 400mm x 515mm

*Net Weight 24.6kg/ctn

*Finish Piano Walnut
