• Rhodium or gold-plated α (Alpha) Pure Copper Conductor (0.8mm)
• Nonmagnetic stainless conductor spring system
• Body material: Nylon/fiberglass with piezo ceramic and carbon damping material
Rhodium or gold-plated α (Alpha) Pure Copper Conductor (0.8mm)
Nonmagnetic stainless conductor spring system
Body material: Nylon/fiberglass with piezo ceramic and carbon damping material
Cover material: Polycarbonate
Parts set with nonmagnetic 2.0mm-thick stainless brace plate
Specified for wire diameters of 4mm (set screw)
Dimensions: 104.0 mm (L) x 47.2 mm (W) x 28.0 mm (H)
Total attention to detail and build quality extends right down to a specially designed patent-pending conductor pressure plate (see below) that increases contact area
Furutech spade terminal FP-209 recommended for 10 AWG wire
