REL Acoustics NEW T5i Subwoofer Speaker

*Purity Reimagined
The Stunningly Simple T/5i

Simplify, Then Add Lightness: Simplicity is its own reward and T/5i reduces the classic cubic sub to its bare essence. A single, high quality AlloyFibre composite driver and down firing orientation produces maximum coupling with the floor and eliminates the need for a grille. T/5i is the purest expression of REL.

We began by updating our classic 8 bass engine to reduce mass, while greatly increasing stiffness. This improvement led to upgrading cabinet dimensions and wall thickness to better control the deep bass. Additional upgrades extended even into the design of our feet, resulting in greater speed and solidity to the presentation of sound.

*Faster & Deeper
A 360º Update

We began by updating our classic 8 bass engine to reduce mass, while greatly increasing stiffness. This improvement led to upgrading cabinet dimensions and wall thickness to better control the deep bass. Additional upgrades extended even into the design of our feet, resulting in greater speed and solidity to the presentation of sound.

*Proven Power
RELs Reliable Brains And Brawn

RELs electronics are the brains and power behind our success. Serie Ti uses the same Class A/B power amplifier sections with large, high current power supplies, precision-wound transformers and an amazing reliability record that has powered some 100,000 RELs.

Specifications
TYPE
Closed Box, down-firing driver

ACTIVE DRIVER SIZE & MATERIAL
8 in., 200mm long-throw, FibreAlloy inverted aluminium dust cap, steel chassis, white cone

PASSIVE RADIATOR SIZE & MATERIAL
N/A

LOW FREQUENCY EXTENTION
-6dB at 32 Hz

INPUT CONNECTORS
High Level Neutrik Speakon, Low Level single RCA, LFE RCA

OUTPUT CONNECTORS
N/A

POWER OUTPUT
125 watts (RMS)

AMPLIFIER TYPE
Class A/B

WIRELESS CAPABILITY
Arrow (Optional), Zero Compression, Single Large Scale Integrated Chip

Protection System
FULLY ELECTRONIC SET SAFE
Yes

D.C. FAULT
Yes

OUTPUT SHORT
Yes

MAINS INPUT VOLTAGE
220-240 volts, 110-120 volts for certain markets

FUSES
1.6 Amp semi delay 230 volts operation, 3.15 Amp semi delay 115 volts operation

Dimensions
W X H X D
10.5 x 12.5 x 12.7 in. (267 x 317 x 322 mm)

NET WEIGHT
26.5 lbs. (12 kg)

FINISH
High Gloss Black, High Gloss White, 5 coats

Supplied Accessories
MAINS LEAD
Yes

NEUTRIK SPEAKON
Yes (10 Meters Nominal)

INTERCONNECT
