Rotel A-10 MKII

The A10 is a 40-watt per channel integrated amplifier that will satisfy the audio purist who doesnt require high power output or digital streaming capability. Its straightforward operation is refreshing and its performance is a pleasure to listen to.

If you are considering taking your first step into a true hi-fi system or are seeking a small, high quality audio system for another living space, you cant do better than the A10 integrated amplifier. The A10 is all about maximum performance for the price. Its design strips away added features that increase the overall cost and can detract from your musical enjoyment.

Simple to operate and a pleasure to listen to, the A10 has connectivity for all your listening sources including an analogue media input (3.5mm mini-jack) for iOS devices or other media players, a CD input, a MM phono input in case your taste runs to classic LPs, a Tuner input to listen to your favourite radio stations and two Aux inputs for other analogue source devices.

Specifications

DIMENSIONS (W × H × D)
430 × 73 × 347mm
17 x 2 7/8 x 13 5/8

FRONT PANEL HEIGHT
60 mm (2 3/8)

POWER REQUIREMENTS
120V, 60Hz

POWER CONSUMPTION
150W

STANDBY POWER CONSUMPTION
<0.5W

NET WEIGHT
6.6 kg, 14.5 lbs

BTU RATING (4Ω, 1/8th power)
450 BTU/h

POWER OUTPUT
50W/Ch (All channels driven, 8Ω)

TOTAL HARMONIC DISTORTION (THD)
<0.03%

FREQUENCY RESPONSE
Line Level Inputs: 10Hz 100kHz, -0.5dB, +0.05dB
Phono Input: 20Hz 20kHz, -0.5dB, +0.3dB

S/N RATIO (IHF A Weighted)
Line Level Inputs: 90dB
Phono Input: 85dB
