FOCUSRITE REDNET HD32R

Focusrite RedNet HD32R
Bridge Interface สำหรับการใช้งานระบบRednetร่วมกันกับ Protools HD/HDX ที่ใช้การเชื่อมต่อด้วยระบบ Ethernet โดยทำงานผ่าน Dante Audio Networking

Pro Tools RedNet Bridge with Redundancy
Connect your RedNet network to Pro Tools | HD or Pro Tools | HDX systems with the Focusrite RedNet HD32R 32-channel HD Bridge, with redundant power supplies and redundant networking for maximums stability and peace of mind in live sound and broadcast applications. Weve helped configure countless RedNet systems here at , and the RedNet HD32R is amazingly easy to integrate with any Pro Tools rig. Via a simple Ethernet cable you can take up to 32 channels of audio and, with the help of a single RedNet HD32R unit, bridge them into Pro Tools | HD via DigiLink. Connect multiple units for larger track counts. Focusrites RedNet HD32R syncs your entire RedNet system to any incoming digital clock or word clock. Get your audio into Pro Tools with the Focusrite RedNet HD32R 32-Channel HD Bridge.

Focusrite RedNet HD32R 32-channel HD Bridge Ethernet Network Connection Features

Route up to 32 inputs and 32 outputs from your RedNet network direct into Pro Tools | HD via DigiLink

Connect up to 3 RedNet HD32R units for 96 inputs and outputs the max supported by Pro Tools | HD

Redundant networking via two Neutrik Ethercon locking network connectors
Redundant power supplies for maximum system reliability in any environment

Upgrade to RedNet interfaces while remaining fully compatible with your saved sessions

Synchronizes your RedNet system to any incoming digital clock or a word clock source

JetPLLTM jitter-reduction technology
Up to 6 RedNet systems can be connected to a Pro Tools | HDX system for a total of 192 tracks @ 96kHz

Sample rate accuracy (internal sync source): <10ppm supported sample rates: 44.1, 48, 88.2, 96, 192khz Word Clock input via BNC port
Word Clock output via BNC port

Dante Ethernet port
