Wharfedale Pro DELTA-X15M / DELTA X SERIES REFINEMENT IN DETAIL

Wharfedale Pro Delta-X 15M
Wharfedale Pro Delta-X 15M ลำโพงที่ออกแบบสำหรับวางเป็น ลำโพงมอนิเตอร์เวที ให้นักดนตรีได้ฟังโดยเฉพาะ โดยมีดอกวูฟเฟอร์ขนาด 15นิ้ว จำนวน 1ดอก และเสียงแหลม 2นิ้ว titanium compression driver

SPECIFICATIONS

Model Name
DELTA-X15M
System Type
Passive
Configuration
Two-way
Frequency Response (+/-3dB)
55-20kHz
Frequency Range (-10 dB)
50-20kHz
Sensitivity (2.83v/1m)
98dB
Calculated Maximum SPL @1m
131dB
System Rated Impedance
8Ω
Low Frequency Transducer

Size
404mm / 15 Paper
Voice Coil Size
77.1mm / 3
Rated Impedance
8Ω
LF Power (re:AES2-2012)
500W
High Frequency Transducer

HF Driver Type
Compression Driver
Voice Coil Size
50.8mm / 2 Titanium
Exit Size
35.6mm / 1.4
Diaphragm Material
Titanium
Rated Impedance
8Ω
HF Power (re:AES2-2012)
50W
Nominal Coverage (H x V)
90 x 45
Power

System Continuous Power
500W
System Programme Power
1000W
System Peak Power
2000W
Crossover frequency
1.8kHz
Input Connector
2 x NL4 (speakON Compatible)
Hardware

Handles
2 on Sides
Enclosure

Enclosure Material
15mm Plywood
Finish
black paint
Grille Material & Finish
1.5 mm Steel Black
Dimensions Unpacked

Height
493(SITU)mm / 19.4
Width Front
446mm / 17.6
Width Rear
446mm / 17.6
Depth
685mm / 27.0
Dimensions Packed

Height
518mm / 20.4
Width Front
757mm / 29.8
Width Rear
757mm / 29.8
Depth
565mm / 22.2
Weight

Net Weight (kg / lbs)
27.24kg / 59.9lbs
Gross Weight (kg / lbs)
33.96kg / 74.7lbs
