Klipsch KPT-8000M 2-WAY SURROUND FOR SMALLER CINEMAS

รายละเอียดสินค้า
SPECIFICATIONS
FREQUENCY RESPONSE1 (+/- 3 dB) 75 Hz 20 kHz (10 dB @ 48 Hz)
POWER HANDLING2 AES: 100 watts (21V)
IEC: 125 watts (23.5V)
MAXIMUM SPL3 116 dB Continuous 122 dB Peak
SENSITIVITY4 97.5 dB @ 2.83V / 1M 95 dB @ 1W / 1M
COVERAGE Horizontal: 90° +/ 20° 2 kHz 20 kHz
Vertical: 90° +20°/40° 2 kHz 20 kHz
DIRECTIVITY INDEX (DI) 7.5 dB +/- 1 dB 2 kHz 20 kHz
DIRECTIVITY FACTOR (Q) 5.6 2 kHz 20 kHz
NOMINAL IMPEDANCE 8 ohms, (minimum 4.4 ohms @ 217 Hz)
CROSSOVER FREQUENCY 1.9 kHz 12 dB/Octave LF 18 dB/Octave HF
COMPONENTS One K-8-ST 8"" woofer
One K-103-TI-KP 1 titanium compression driver on a K-802 horn
INPUT CONNECTION Four point barrier strip
BRACKET SCREW PATTERN 4 screw: 2.75 (6.9cm) x 5 (12.7cm)
INCLUDED SCREWS (4) 1.125 (2.86cm) 1/4 Bottom: 13 (33cm)
ENCLOSURE MATERIAL ABS + 10% glass
GRILLE Power-coated steel
HEIGHT 18.7 (47.5cm)
WIDTH Top: 14.7 (37.3cm)
Bottom: 13 (33cm)
DEPTH Top: 7.2 (18.3cm)
Bottom: 4.7 (11.9cm)
WEIGHT 15.77 lbs (7.15kg)
TILT Built-in 8° downward angle with 15° angle option
SAFETY CABLE INSERT 3/8 1/4-20 threaded
ACCESSORIES
SB-6 mounting bracket
SB-7 mounting bracket
SB-9 mounting bracket"
